SonicWall NSv 870 Secure Upgrade Plus Advanced Edition

SKU: 03-SSC-0024

£17,696.07

£13,080.93

License duration *

General
Operating system	SonicOSX
Supported Hypervisors	VMware ESXi v5.5 / v6.0 / v6.5 / v6.7, Microsoft Hyper-V, KVM Ubuntu 16.04 / CentOS 7
Supported Public Cloud Platforms	AWS (c5.2xlarge), Azure (Std D4 v2)
Licensing	BYOL, PAYG
Max Supported vCPUs	8
Interface Count (ESXi/Hyper-V/KVM/AWS/Azure)	8/8/8/8/8
Max Mgmt/DataPlane Cores	1/7
Min Memory	10GB
Max Memory	14GB
Supported IP/Nodes	Unlimited
Minimum Storage	60GB
SSO users	15000
Logging	Analyzer, Local Log, Syslog
High availability	Active/Passive

Firewall/VPN Performance
Firewall inspection throughput	14.0 Gbps
Threat Prevention throughput	14.0 Gbps
IPS throughput	8.0 Gbps
TLS/SSL decryption and inspection throughput (DPI SSL)	4.0 Gbps
Connections per second	75640
Maximum connections (SPI)	3 million
Maximum connections (DPI)	2 million
TLS/SSL DPI Connections	30 000

VPN
Site-to-site VPN tunnels	10000
IPSec VPN clients (maximum)	2000 (6000)
SSL VPN Clients Included	2
SSL VPN Clients Maximum	300
Encryption/authentication	DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B, Common Access Card (CAC)
Key exchange	Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN	RIP, OSPF, BGP

Networking
IP address assignment	Static, DHCP, internal DHCP server, DHCP relay
NAT modes	1:1, many:1, 1:many, flexible NAT (overlapping IPs), PAT
Max VLAN	128
Routing protocols	BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS	Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
Authentication	XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
