Firewall General
|
| Operating system |
SonicOS 7.0.1 |
| Interfaces |
2x40G; 8x25G, 4 x10G/5G/2.5/1G SFP+, 4 x 10G/5G/2.5G/1G (Cu), 16 x 1GbE (Cu), 2 USB 3.0, 1 Console, 1 Mgmt. port |
| Expansion |
Storage Expansion Slot (Up to 1TB) |
| Storage |
256GB M.2 |
| VLAN Interfaces |
512 |
| Access points supported (maximum) |
512 |
Firewall/VPN Performance
|
| Firewall inspection throughput |
36 Gbps |
| Threat Prevention throughput |
19 Gbps |
| Application inspection throughput |
20 Gbps |
| IPS throughput |
20 Gbps |
| Anti-malware inspection throughput |
18.5 Gbps |
| TLS/SSL decryption and inspection throughput (DPI SSL) |
9 Gbps |
| IPSec VPN throughput |
19 Gbps |
| Connections per second |
228 000 |
| Maximum Connections (SPI) |
8 000 000 |
| Maximum DPI-SSL Connections |
750 000 |
| Maximum connections (DPI) |
6 000 000 |
VPN
|
| Site-to-site tunnels |
6000 |
| SSL VPN licenses (max) |
2 (1500) |
| IPSec VPN clients (max) |
2000 (6000) |
| Encryption/Authentication |
DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography |
| Key exchange |
Diffie Hellman Groups 1, 2, 5, 14v |
| Route-based VPN |
RIP, OSPF, BGP |
| Certificate support |
Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP |
| VPN features |
Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN |
| Global VPN client platforms supported |
Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10 |
| NetExtender |
Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE |
| Mobile Connect |
Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome, Windows 8.1 (Embedded) |
Security Services
|
| Deep Packet Inspection services |
Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL |
| Content Filtering Service (CFS) |
HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists |
| Comprehensive Anti-Spam Service |
Supported |
| Application Visualization |
Yes |
| Application Control |
Yes |
| Capture Advanced Threat Protection |
Yes |
Networking
|
| IP address assignment |
Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay |
| NAT modes |
1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode |
| Routing protocols |
BGP, OSPF, RIPv1/v2, static routes, policy-based routing |
| QoS |
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p |
| Authentication |
LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC) |
| Local user database |
3200 |
| VoIP |
Full H323-v1-5, SIP |
| Standards |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
| Certifications pending |
FIPS 140-2 (with Suite B) Level 2, UC APL, VPNC, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS) |
| High availability |
Active/Active with stateful synchronization |
Hardware
|
| Form factor |
1U Rack Mountable |
| Power supply (W) |
1x350W |
| Maximum power consumption (W) |
139.2 |
| Input power |
100-240 VAC, 50-60 Hz |
| Total heat dissipation |
474.7 BTU |
| Dimensions |
43 x 46.5 x 4.5 (cm) 16.9 x 18.1 x 1.8 in |
| Weight |
8.1 kg |
| WEEE weight |
9.9 kg |
| Shipping weight |
13.8 kg |
| Major regulatory |
FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI |
| Environment (Operating/Storage) |
32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C) |
| Humidity |
0-90% non-condensing |
