Firewall General
|
Operating system |
SonicOS 7.0.1 |
Interfaces |
24x1GbE, 6x10G SFP+, 4x5G SFP+, 2 USB 3.0, 1 Console, 1 Management port |
Expansion |
Storage Expansion Slot (Up to 256GB) |
Storage |
128GB M.2 |
VLAN Interfaces |
256 |
Access points supported (maximum) |
32 |
Firewall/VPN Performance
|
Firewall inspection throughput |
5.5 Gbps |
Threat Prevention throughput |
3.5 Gbps |
Application inspection throughput |
4.2 Gbps |
IPS throughput |
3.8 Gbps |
Anti-malware inspection throughput |
3.5 Gbps |
TLS/SSL decryption and inspection throughput (DPI SSL) |
850 Mbps |
IPSec VPN throughput |
2.2 Gbps |
Connections per second |
22500 |
Maximum Connections (SPI) |
2000000 |
Maximum DPI-SSL Connections |
150000 |
Maximum connections (DPI) |
750000 |
VPN
|
Site-to-site tunnels |
3000 |
SSL VPN licenses (max) |
2 (500) |
IPSec VPN clients (max) |
50 (1000) |
Encryption/Authentication |
DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography |
Key exchange |
Diffie Hellman Groups 1, 2, 5, 14v |
Route-based VPN |
RIP, OSPF, BGP |
Certificate support |
Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP |
VPN features |
Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN |
Global VPN client platforms supported |
Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10 |
NetExtender |
Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE |
Mobile Connect |
Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome, Windows 8.1 (Embedded) |
Security Services
|
Deep Packet Inspection services |
Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL |
Content Filtering Service (CFS) |
HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists |
Comprehensive Anti-Spam Service |
Supported |
Application Visualization |
Yes |
Application Control |
Yes |
Capture Advanced Threat Protection |
Yes |
Networking
|
IP address assignment |
Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay |
NAT modes |
1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode |
Routing protocols |
BGP, OSPF, RIPv1/v2, static routes, policy-based routing |
QoS |
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p |
Authentication |
LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC) |
Local user database |
250 |
VoIP |
Full H323-v1-5, SIP |
Standards |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
Certifications pending |
FIPS 140-2 (with Suite B) Level 2, UC APL, VPNC, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS) |
High availability |
Active/Active with stateful synchronization |
Hardware
|
Form factor |
1U Rack Mountable |
Power supply (W) |
90 |
Maximum power consumption (W) |
36.3 |
Input power |
100-240 VAC, 50-60 Hz |
Total heat dissipation |
123.78 BTU |
Dimensions |
43 x 32.5 x 4.5 (cm) 16.9 x 12.8 x 1.8 in |
Weight |
4.6 kg / 10.2 lbs |
WEEE weight |
4.8 kg / 10.6 lbs |
Shipping weight |
7.0 kg / 15.4 lbs |
Major regulatory |
FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI |
Environment (Operating/Storage) |
32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C) |
Humidity |
5-95% non-condensing |
